Victorian Elevator
$16,999.00
* plus shipping & installation
Best Price
Guarantee
1 (859) 494-5235
Have Any Questions?
Call us! We're here to help. 1 (859) 494-5235
Have Any Questions?
We're here to help. 1 (859) 494-5235
Have Any Questions?
Call us! We're here to help. 1 (859) 494-5235
Have Any Questions?
Call us! We're here to help. 1 (859) 494-5235
Specifications
Applications | Indoor Residential |
Capacity | 950 lb |
Maximum Travel Distance | 40' |
Cab Dimensions (standard) | 36x36 (inline only) / 36x48 |
Cab Dimensions (optional) | Up to 15 ft sq / 90 degree requires 38" width |
Speed (per minute) | 40' |
Minimum Overhead Required | 106" |
Drive | Winding Drum |
Motor/Pump | 3 HP |
Cab Heights | 84" |
Max Landings | 4 |
Power Requirement | 220V 1Ph |
Pit Depth | 10 inches |
Safety | Emergency Lighting, Emergency Lowering with DC Backup, Emergency Stop Alarm, Door Interlock |
Specifications
Applications | Indoor Residential |
Capacity | 950 lb |
Maximum Travel Distance | 40' |
Cab Dimensions (standard) | 36x36 (inline only) / 36x48 |
Cab Dimensions (optional) | Up to 15 ft sq / 90 degree requires 38" width |
Speed (per minute) | 40' |
Minimum Overhead Required | 106" |
Drive | Winding Drum |
Motor/Pump | 3 HP |
Cab Heights | 84" |
Max Landings | 4 |
Power Requirement | 220V 1Ph |
Pit Depth | 10 inches |
Safety | Emergency Lighting, Emergency Lowering with DC Backup, Emergency Stop Alarm, Door Interlock |
