Specifications

Weight Capacity500 lb
Overall Length47"
Overall Width25.5"
Seat Depth18.5"
Seat Width22"
Per-Charge Range, Maximum18 mi
Maximum Speed5.8 mph
Turning Radius49"
Weight, without batteries183.5 lb
Weight, with batteries256.5 lb
Heaviest Piece Weight66.5 lb
Disassembly7 Pieces
Front Wheel Diameter10"
Rear Wheel Diameter10"
Ground Clearance4.25"
Tire TypeSolid
Drivetrain TypeSealed Transaxle
Motor Type24 Volt DC
Brake TypeElectro-mechanical, Regenerative
Controller TypeUltra Heavy Duty 110 Amp
Battery Type(2) 22NF or (2) U-1
Battery Weight76 lb
Battery ChargerOff-board, 5 Amp
Goes In ReverseYes
Freewheel ModeYes
Tiller StyleHandle Bar

Specifications

Weight Capacity500 lb
Overall Length47"
Overall Width25.5"
Seat Depth18.5"
Seat Width22"
Per-Charge Range, Maximum18 mi
Maximum Speed5.8 mph
Turning Radius49"
Weight, without batteries183.5 lb
Weight, with batteries256.5 lb
Heaviest Piece Weight66.5 lb
Disassembly7 Pieces
Front Wheel Diameter10"
Rear Wheel Diameter10"
Ground Clearance4.25"
Tire TypeSolid
Drivetrain TypeSealed Transaxle
Motor Type24 Volt DC
Brake TypeElectro-mechanical, Regenerative
Controller TypeUltra Heavy Duty 110 Amp
Battery Type(2) 22NF or (2) U-1
Battery Weight76 lb
Battery ChargerOff-board, 5 Amp
Goes In ReverseYes
Freewheel ModeYes
Tiller StyleHandle Bar

** Pride® FDA Class II Medical Devices are designed to aid individuals with mobility impairments.
