XSSMLXL

Specifications

ApplicationsIndoor
Capacity1,000 lb
Maximum Travel Distance40 feet
Cab Dimensions (standard)36" x 48"
Cab Dimensions (optional)42" x 42" 42" x 48"
Speed (per minute)40'
Drive1:2 Roped Hydraulic
Cab Heights84"
Max Landings4
Overhead Clearance Required84" Cab Requires 96" or 108", 96" Cab Requires 108" or 120" (Manual or Automatic Doors)
Power Requirement220 VAC Single Phase
Pit Depth12"
EmergencyEmergency lighting, Emergency Lowering with DC Backup, Emergency Stop Alarm
SafetyDual Rope, Commercial Level Mechanical Brakes, E-stops on both Pit and Car Top, Shoring Blocks for Safe Technician Working

Specifications

ApplicationsIndoor
Capacity1,000 lb
Maximum Travel Distance40 feet
Cab Dimensions (standard)36" x 48"
Cab Dimensions (optional)42" x 42" 42" x 48"
Speed (per minute)40'
Drive1:2 Roped Hydraulic
Cab Heights84"
Max Landings4
Overhead Clearance Required84" Cab Requires 96" or 108", 96" Cab Requires 108" or 120" (Manual or Automatic Doors)
Power Requirement220 VAC Single Phase
Pit Depth12"
EmergencyEmergency lighting, Emergency Lowering with DC Backup, Emergency Stop Alarm
SafetyDual Rope, Commercial Level Mechanical Brakes, E-stops on both Pit and Car Top, Shoring Blocks for Safe Technician Working
